Schüco Windows System AWS 75
Download BrochureHighly thermally insulated windows system for sophisticated design requirements.
The aluminium system is part of the Schüco AWS modular range, featuring optimised characteristics in terms of function, energy efficiency and design.
Highlights
- Outstanding thermal insulation
- Slimline design
- Wide range of opening types
| Air permeability | Class 4 |
|---|---|
| Warranty | 10 years |
| Wind load resistance | Class C5 / B5 |
| CE marking | Yes |
| Burglar resistance | Up to RC 2 |
| Watertightness | Class 9A |
| Max. sound reduction index | 46 dB(A) |
| Max. vent height | 2500 mm |
| Max. vent width | 1450 mm |
| Max. glass/panel thickness | 50 mm |
| Uf value of frame | 1.7 W/(m²·K) |
| Min. face width | 55 mm |
